Stackable Asphalt Heating Tank LR Registered Space And Freight
Saving
Introduction
Asphalt Heating Tank is the most commonly used bitumen tank which
can heat and store all kinds of bitumen, its structure is very
compact, easy manufacturing and high heating efficiency.
Changshi can also provide components for large liquid storage tanks
fabricated on site at terminals.
- The height of the spray boom can be adjusted at will according to
the construction requirements.
- With circulation and pump in and out function.
- Cleaning function: equipped with independent water tank (300L)
cleaning pipeline, a set of pneumatic cleaning configuration.
- The asphalt sampling function is installed in the tank.
- Spreading medium: emulsified asphalt.12. Stainless steel scrub,
with Insulating layer
Features and technical data:
| No. | Description | Specification | Remarks |
| 1 | Name | Asphalt Tank | 20 feet |
| 2 | Effective capacity(m3) | 26 | |
| 3 | Outline dimension(mm) | 6058*2438*2591 | |
| 4 | Total weight of tank(T) | 5.5 | |
| 5 | Insulation layer(mm) | 50 | |
| 6 | The temperature down rate of the asphalt transport tank(℃/h) | ≤2 | |
| 7 | Seal off the head(mm) | 8 | |
| 8 | Direct visual temperature meter | 1 | |
| 9 | Temperature sensor | 1 | |
| 10 | Maintenance manhole | 1 | Ø500 mm |
| 11 | The feeding hole of the asphal | 1 | Ø250 mm |
| 12 | The protect frame of the feeding hole of the asphalt | 1,800*750*200 mm | overflowing hole |
| 13 | Automatic control system | 1 | Optional |
| 14 | Diesel oil burner | 2
|
Standard configurations:
1.Tank material: carbon steel
2. Head: water head
3. Steel plastic wave proof plate: double corrugated, surface
lining plastic PE
4. Sub warehouse
5. Main valve: built in valve
6. Artesian mouth: after the end of a 3 inch artesian mouth, with
Aluminum alloy ball valve
7. heat system : burner heating
Our Service:
The extremely considerate and sincerely service would be provided
to our customers immediately in CNCAC once made the order.
Including:
1. Operator training if requested;
2. Spare parts supply free or paid;
3. Life-long technical support;
4. Installation, commissioning and training and on-site technical
guide services are available;
5. Welcome to visit our factory at any time.
